Bringing a custom 3D model into Source Filmmaker (SFM) involves a systematic compilation process. Below is a complete, detailed walkthrough of how SFM Compile works, following your outline in full detail with no extra unrelated content.

1. Prepare Your Assets

The first stage is preparation. Every asset must be properly organized and formatted before compilation.

Asset Organization

• • You must create separate folders for each type of asset. For example:

    • A models folder to hold the geometry files (.SMD, .FBX, .DMX).

    • A textures folder for all material textures.

    • An animations folder for any animation files.

    • A QC files folder (or the same folder) for the QC scripts.

  • You must ensure consistent naming conventions so references in QC files and paths match exactly (case-sensitive in many cases).

Exporting from 3D Software

• From Blender or Maya, export your model(s) into one of these accepted formats:

  • .SMD

  • .FBX

  • .DMX

• Each exported file should correspond to what you reference in the QC file later.

• You may need to configure the exporter settings (scale, axis orientation, normals, skeleton) so the model behaves correctly in SFM.

By the end of this stage, you should have a clear directory layout and working exported files that mirror what your QC file expects.

2. Write or Edit QC File

The QC file is central to the compile process. It instructs the compiler how to build the model, where resources are, and what animations to include.

What a QC File Defines

Inside the QC file, these elements must be defined:

• Model name: the output name of the compiled model (the .mdl file).

• Texture directory: where the compiler will look for textures (relative paths).

• Bone structure: linking mesh to skeleton, assigning correct bones.

• Animation references: pointing to sequences (idle, walk, etc.), with frame rate values and file names.

Example QC File with Detail

Here is the sample QC script with all references:

• $modelname "my_model.mdl": This tells the compiler to name the resulting model file my_model.mdl.

• $cdmaterials "models\my_textures": This specifies that textures will be located under models\my_textures relative to game paths.

• $body "Body" "my_model_ref.smd": Indicates the mesh part called “Body” uses the file my_model_ref.smd.

• $sequence "idle" "my_model_idle.smd" fps 30: Defines an animation sequence named “idle” coming from my_model_idle.smd and playing at 30 frames per second.

You might include multiple $sequence lines for different animations (walk, run, jump), but for our outline, one sequence is shown.

3. Compile the Model

Once assets and the QC file are ready, you run the compile step. This transforms your source files into SFM-ready output.

Tools Used for Compilation

• Crowbar: A GUI tool many use for compiling because it simplifies some command-line complexity.

• Command-line studiomdl: The underlying compiler that reads QC and source files.

Inputs and Outputs

• Inputs to the compiler:

  • The QC file you created

  • The referenced .SMD, .FBX, or .DMX files

  • Textures and material files referred to in QC

• Outputs generated by the compile:

  • .MDL file (the main model)

  • .VTX file (vertex-level data)

  • .PHY file (physics definitions)

  • Possibly .ANI or other related files if you have animations

When compilation succeeds, you get a set of output files ready to be used in SFM.

4. Check and Fix Errors

Compilation often produces errors or warnings. You must inspect and correct them before using the model.

Steps for Error Handling

• Open the log file generated by the compiler (Crowbar or studiomdl provides this).

• Read through all error messages, such as:

  • “File not found” (texture, mesh, or QC reference)

  • Typographical errors in file names or paths

  • Syntax issues in QC directives

  • Missing bones or mismatched skeleton references

• For each error, modify your QC file, file names, or folder placement to resolve the issue.

• After corrections, re-run the compilation until there are no critical errors.

The log file is your guide, it pinpoints what’s broken and where.

5. Load into SFM

Once the model compiles cleanly, you bring it into Source Filmmaker for use.

Placement of Compiled Files

• Move the .MDL, .VTX, .PHY, and other outputs into SFM’s model folder, e.g.Steam/steamapps/common/SourceFilmmaker/game/usermod/models/

Spawning the Model in SFM

• Launch Source Filmmaker.

• Use the Animation Set Editor.

• Click Create Animation Set for New Model.

• Type the compiled model’s name (for instance, my_model.mdl).

• The model spawns in your scene, ready for animation and interaction.

Important Reminder

Compilation is not always smooth. Even a single typo or missing texture will break the process. Always use the compiler logs to spot mistakes and recompile after fixes. Logs are your best friend in this process.
